SolaHD
ACTIVE TRK FILTER 1PH 3A 120V DIN
Part Number: IE-103
UPC: 00633914074265
Call for Price
- Manufacturer availability unknown.
Quantity:
Changes Selections Above Amperage Rating...
Changes Selections Above Type...
Changes Selections Above Voltage Rating...
Changes Selections Above Short Circuit Rating...
Product Overview
Islatrol IE Series Active Tracking Filter, 120 V/Continuous Current 3 Amps,
Specifications
Details
Product Height:
3.30"
Product Width:
7.20"
Product Length:
6.20"
Electrical Category:
Electrical Distribution Equipment
, Fuses Relays And Circuit Breakers
Electrical Subcategory:
Surge And Power Protection
, Circuit Protection Devices And Accessories
Amperage Rating:
7.5
Application:
Industrial or office equipment, computers placed in harsh environments.
Brand Name:
SolaHD
Class:
Category B Ringwave (6kv, 500 A, 100 kHz)
Connection:
Barrier strip at input and output/with wire leads at input and output
Country Of Origin:
MX
Environmental Conditions:
Humidity: 0 to 95%
Frequency Rating:
47-63
Material:
High Impact Plastic Case, Vacuum Impregnated Magnetics, Epoxy Encapsulated
Mounting:
Flange Dimensions: 6.75 x 3.50 x 7.75 x 0.19
Operating Temperature:
-40 DEG C to +45 DEG C at Full Load; Derate Linearly to 60% at +70 DEG C
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
Phase:
Single
Response Time:
Normal Mode <0.5ns; Common Mode <5ns
RoHS Compliance:
Yes
Short Circuit Rating:
Surge current capacity -- 45,000 Amps
Size:
6.25 Length x 4.75 Width x 2.35 High
Spec Sheet:
Special Features:
Reduces normal mode transients to +/-2 volts. Surge current capacity - 45,000 Amps. Transient protection in all modes: line to neutral, line to ground, and neutral to ground. LED power indication
Standard:
UL 1283, CSA Recognized
Stock Type:
Shelf Stock
Sub Brand:
Edco
Type:
Islatrol IC+ Series
Type Of Indicators:
LED Power Indicators
UNSPSC:
39121610
Voltage Rating:
240 Volt/275 VRMS
Warranty Link:
Weight:
.900 L
