Image may not reflect selected features
No Image
Available
Available
Panduit
Cu,Cbl,Cat6A,4Pr,23AWG,UTP,WH,1000ft
Part Number: PUC6A04WH-EG
UPC: 00074983394906
Call for Price
- Manufacturer availability unknown.
Quantity:
Changes Selections Above Length...
Changes Selections Above Insulation Material...
Changes Selections Above Jacket Material...
Changes Selections Above Outside Diameter...
Product Overview
Copper cable, category 6A UTP, CM, 4-pair, conductors are 23 AWG, twisted in pairs, separated by an integrated pair divider, surrounded by a patent-pending matrix tape and protected by a PVC jacket, white.
Specifications
Details
Product Height:
11.70"
Product Width:
15.75"
Electrical Category:
Wire And Cable
Electrical Subcategory:
Electrical Cable
Electrical Subtype:
Copper Cable
Application:
Indoor
Brand Name:
Panduit®
Color:
White
Conductor Material:
Copper
Construction:
U/UTP
Country Of Origin:
CHN
Installation Link:
Insulation Material:
NA
Jacket Material:
Polyvinyl Chloride
Length:
1000
, 15.7500 IN
Number Of Conductors:
4
Order Minimum:
18.000 RL
Order Multiple:
18.000 RL
Outside Diameter:
0.3
Resistance:
Flame-Resistant
RoHS Compliance:
Yes
Spec Sheet:
Standard:
Exceeds the requirements of ANSI/TIA-568-C.2 Category 6A and ISO 11801 Class EA standards; Exceeds the ANSI/TIA-568-C.2 Category 6A and IEC 61156-5 Category 6A standards; PoE compliant: Meets IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt for PoE application
Stock Type:
Configured on order
Sub Brand:
Pan-Net®
Temperature Rating:
167
Type:
Copper Cable
UNSPSC:
26121634
Voltage Rating:
NA
Weight:
39/1000 ft.
, 52.830 L
