Panduit

Copper Cable, Premium Cat 6, 4-Pair, 23

Copper Cable, Enhanced Category 6, 4 Pair, 23 American Wire Gauge (AWG), Unshielded Twisted Pair (UTP), CMR, Red, 1000 Feet (305 Meter). Exceeds requirements of ANSI/TIA-568-C.2 Category 6 and ISO 11801 2nd Edition Class E channel standards. Exceeds requirements of ANSI/TIA-568-C.2 and IEC 61156-5 Category 6 component standards. Meet requirements of IEEE 802.af and IEEE 802.3at for PoE applications. Reduced attenuation maximizes the amount of signal that reaches the receiver, increasing bandwidth. Third party tested to comply with ANSI/TIA/EIA-568-C.2. Cable diameter of 0.265 inch (6.8mm) nominal. Installation temperature range of 32 degrees F to 122 degrees F (0 degrees C to 50 degrees C). Operating temperature range of 14 degrees F to 140 degrees F (-10 degrees C to 60 degrees C). Descending length cable markings enable easy identification of remaining cable which reduces installation time and cable scrap. Cable supplied in an easy payout reel-in-a-box.
