Fuse Block 750VAC 750VDC 50A Adder Box

Mersen
Fuse Block 750VAC 750VDC 50A Adder Box

Part Number: U70505
UPC: 00782001323578
Call for Price
  • Manufacturer availability unknown.
Changes Selections Above Size...
Changes Selections Above Connection...
Changes Selections Above Amperage Rating...
Changes Selections Above Number Of Poles...
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
Fuse Block 750VAC 750VDC 50A Adder Box
Specifications
Details
Product Height:
1.37"
Product Width:
0.97"
Product Length:
3.00"
Electrical Category:
Fuses Relays And Circuit Breakers
Electrical Subcategory:
Fuses
Amperage Rating:
50
Application:
All circuits up to 750 volts using semiconductor fuses for protection of small inverters, UPS systems, motor drives, etc.
Brand Name:
Mersen
Class:
IEC Cylindrical 14x51mm
Connection:
Box
Country Of Origin:
MX
Material:
Thermoplastic
Mounting:
Screw Mount or DIN Rail
Number Of Poles:
1
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
Phase:
1
RoHS Compliance:
Yes
Size:
3 x 0.97 x 1.37
Spec Sheet:
Spec Link
Special Features:
Thermoplastic bases DIN-rail (U710) or Screw Mount Adder block design
Standard:
UL Recognized component guide IZLT2, File E52283 CSA Certified class 6225, File 32169
Stock Type:
Configured on order
Type:
Semiconductor & Special Purpose Fuse Bases & Accessories
UNSPSC:
39121629
Voltage Rating:
750
Weight:
.100 lb
