PLUG HEXAGON NB 075NPT

Appleton Electric
PLUG HEXAGON NB 075NPT

Part Number: 757DT25
UPC: 00781381140447
Call for Price
  • Manufacturer may be Out Of Stock.
Changes Selections Above Connection...
Changes Selections Above Size...
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
757 Series Hexagon Head Stopper Plug, Size: M50, Material: Brass, Enclosure: NEMA 4X, IP68, Finish: Nickel Plated, Connection: 3/4 IN MNPT, Enclosure: IP68, NEMA 4X, Standard: UL 886 (1203), UL File Number E60079-0, E60079-1, E60079-7, CS
Specifications
Details
Product Height:
0.58"
Product Width:
7.40"
Product Length:
10.90"
Electrical Category:
Electrical Boxes And Enclosures
Electrical Subcategory:
Fittings and Bushings
Application:
For Use To Close Any UnUsed Entries In Electrical Equipment
Brand Name:
Appleton
Connection:
3/4 IN MNPT
Country Of Origin:
GB
Enclosure:
NEMA 4X, IP68
Finish:
Nickel Plated
Material:
Brass
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
RoHS Compliance:
Contact Manufacturer
Size:
M50
Spec Sheet:
Spec Link
Special Features:
In general care should be taken to ensure that a suitable entry thread sealing washer is also selected and installed, where applicable, to ensure that an effective seal is made at the entry, thereby maintaining the integrity of the enclosure or equipment I
Standard:
UL 886 (1203), UL File Number E60079-0, E60079-1, E60079-7, CSA C22.2 No. 30, CSA CAN/CSA E60079-0, CAN/CSA E60079-1, CAN/CSA E60079-7; CSA 113642, ATEX 001284U (Component), ATEX 001003 (Equipment), EN 60079-0; EN 60079-1, EN 60079-7, EN 61241-1, IEC 60079
Type:
757 Series Hexagon Head Stopper Plug
UNSPSC:
39121311
Warranty Link:
Warranty Information
Weight:
.250 L
