Copper Cable, Cat 5e, 24 AWG, UTP, Outdo

Panduit
Copper Cable, Cat 5e, 24 AWG, UTP, Outdo

Part Number: IFRH5C04BL-UG
UPC: 00613056346994
Call for Price
  • Manufacturer availability unknown.
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
The Cat 5e UTP copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and wrapped with a foam polypropylene tape to form a core. All four pairs are covered with an industrially rated black PVC jacket which is oil and sunlight resistant and flame retardant. This cable is rated for panel or on-machine applications where space is shared with 600 V high voltage cables. The cable is supplied 305 meters (1,000 feet) to a reel and black.
Specifications
Details
Product Height:
8.00"
Product Width:
9.00"
Product Length:
18.00"
Electrical Category:
Wire And Cable
Electrical Subcategory:
Electrical Cable
Brand Name:
Panduit®
Conductor Material:
Copper
Construction:
F/UTP
Country Of Origin:
USA
Insulation Material:
HDPE
Jacket Material:
High Density Polyethylene
Number Of Conductors:
2
Order Minimum:
1000.000 FT
Order Multiple:
1000.000 FT
Outside Diameter:
0.25
Resistance:
UV Resistant
RoHS Compliance:
Yes
Spec Sheet:
Spec Link
Standard:
Meets or exceeds the requirements of ANSI/TIA-568-C.2 Category 5e; Standard compliances: UL AWM Style 2570 (80°C 600V), Oil Res and Sun Res, UL 444 Sun Res, UL 1666 CMR; CE Compliant: EuroClass Fca; RoHS Compliant
Stock Type:
Configured on order
Sub Brand:
IndustrialNet™
Temperature Rating:
167
Type:
Copper Cable/Industrial
UNSPSC:
26121634
Voltage Rating:
80
Weight:
37.300 L
