JVM-836-1 MILL W/DP700 3AX Q-DRO&X&Y-PWF

Jet - US
JVM-836-1 MILL W/DP700 3AX Q-DRO&X&Y-PWF

Part Number: JT9-691178
UPC:
Call for Price
  • Manufacturer availability unknown.
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
The precision bored and honed milling head, coupled with the hardened and ground 8” x 36” table ensures retention of tolerances, while locks on all moving surfaces increase user safety. The JET JVM-836 has features you've come to expect that are backed by the industry-leading JET Two Year Warranty
Specifications
Details
Industrial Category:
Machining
Industrial Subcategory:
Milling
Base Unit of Measure:
IN
Collet Capacity:
1/8 - 7/8
Commodity Code:
8465.95.0055
Distance Spindle to Column (Max.) (In.):
15-3/4
Enabled:
Yes
End User Sellable:
No
Family:
Vises - Milling
Item Weight (lbs):
1635
Magento Website Mapping:
JET Parts
Max Distance Spindle to Table (In.):
13-3/4
Model Number:
JVM-836-1
Motor (HP):
1-1/2 HP, 115/230V, 1Ph
Number of Axis:
2
Number of Spindle Speeds:
5
Old Item Number:
691178
Overall Dimensions (L x W / in.):
55 x 52 x 78
Prop 65:
Cancer and Reproductive Harm
Quill Diameter (In.):
3-3/8
Quill Down Feed Rates (IPR):
.0015 - .003 - .006
Range of Spindle Speeds (RPM):
240 - 1,550
Ready for Web:
Yes
SAP Country of Origin:
Taiwan
Spindle Taper (In. x TPI):
R-8
Style (Type):
Step Pulley
T-Slot Centers (In.):
2-1/2
Table Cross Travel (In.):
9-1/2
Table Longitudinal Travel (In.):
22-1/4
Table Longitudinal Travel With Powerfeed (In.):
18
Table Size (L x W) (In.):
7-7/8 x 35-3/4
Transportation:
DOCK DEL ONLY
Travel of Knee (In.):
14
Travel of Ram (In.):
10-1/2
UPC:
662755513954
Weight (Lbs.):
1617
Weight (Lbs.) (Unit):
Pound
Work Table Weight Capacity (Lbs.):
500
Other Details
  • Graduated scale on column
  • Hardened and ground precision table
  • Head tilts left or right
  • High precision spindle bearings
  • Large diameter quill is chromed
  • One shot lubrication system
  • Precision bored and honed milling head
  • Precision ground dovetail ways
