6 Hour 125-277 V DPST Ivory

Intermatic
6 Hour 125-277 V DPST Ivory

Part Number: FD46H
UPC: 00078275186040
Call for Price
  • Manufacturer availability unknown.
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
Info & Guides
File
This 6 hour white DPST Decorator Auto-Off Timer is designed to replace any standard wall switch - single or multi-gang. The energy-efficient mechanical timer does not require electricity to operate. In addition, it automatically limits the ON times for fans, lighting, motors, heaters, and other energy consuming loads.
Specifications
Details
Product Height:
4.63"
Product Width:
2.10"
Category:
Lighting Controls
Subcategory:
Lightswitches
Action:
1 x DPST
Amperage Rating:
15
Application:
Indoor, CFLs Lighting, Fans, Electric Motors, Heaters, HVACR
Brand Name:
Intermatic
Connection:
Teeter Type
Contact Configuration:
2 NO
Contact Rating:
7 AMP @ 125 VAC (Tungsten), 20 AMP @ 125 VAC (Resistive), 10 AMP @ 250/277 VAC (Resistive)
Country Of Origin:
TN
Length:
2.9000 IN
Mounting:
Wall Mount
Number Of Poles:
2
Operating Temperature:
-40 to +104 DEG F, -40 to +40 DEG C
Order Minimum:
6.000 EA
Order Multiple:
6.000 EA
RoHS Compliance:
Contact Manufacturer
Size:
2.79 HEIGHT X 1.6 WIDTH X 1.19 DEPTH IN, 70.86 HEIGHT X 40.64 WIDTH X 30.22 DEPTH MM
Spec Sheet:
Spec Link
Special Features:
Features: Energy-Efficient Mechanical Timers do not require Electricity to Operate, Automatically Limit the ON Times, Press-On Knob Design Ensures Quick and Easy Installation, CFL Compatible, Provide Direct Replacement of a Standard Wall Switch in Single o
Standard:
cCSAus Certified, UL Listed, UL Recognized, HVACR
Stock Type:
Shelf Stock
Timer Duration:
6
Timing Range:
6
Type:
Decorator Spring Wound Auto-Off
UNSPSC:
39122208
Voltage Rating:
125 - 277
Wall Plate Color:
Ivory
Weight:
0.380 L
