FD 3P 100A W/ST 12-24VAC /VDC RHTERM L&L

Eaton
FD 3P 100A W/ST 12-24VAC /VDC RHTERM L&L

Part Number: FD3200LS18
UPC: 00782113951171
Call for Price
  • Manufacturer may be Out Of Stock.
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
Eaton Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal, fixed magnetic trip, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, Line and load, 12-24 Vac/dc rear w/ right pigtail, 50/60 Hz
Specifications
Details
Product Height:
4.13"
Product Width:
3.38"
Electrical Category:
Electrical Distribution Equipment , Fuses Relays And Circuit Breakers
Electrical Subcategory:
Breakers , Circuit Breakers And Accessories
Application:
Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
Brand Name:
Eaton
Brochure:
Manufacturer Brochure
Country Of Origin:
DO
Current Rating:
200 A
Frame:
F
Frequency Rating:
50 to 60 Hz
Installation Link:
Installation Instructions
Interrupt Rating:
35 kAIC at 480 Vac|65 kAIC at 240 Vac
Lead Time:
20.000 DW
Length:
6.0000 IN
Number Of Poles:
Three-pole
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
RoHS Compliance:
Contact Manufacturer
Spec Sheet:
Spec Link
Standard:
UL Listed
Tech Drawing Link:
Tech Drawing
Trip Type:
Fixed thermal, fixed magnetic
Type:
Molded case circuit breaker
UNSPSC:
39121616
Video Clip:
Product Video Clip
Voltage Rating:
600 Vac, 250 Vdc
Weight:
4.500 L
