CLASS I DIV.2 PC-120VAC

Appleton Electric
CLASS I DIV.2 PC-120VAC

Part Number: PC120D2
UPC: 00781381090834
Call for Price
  • Manufacturer availability unknown.
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
PCD2 Series Photocontrol, Supply Voltage: 120 V, Connection: (3) 18 AWG Stranded 6 IN Leads, Mounting: 1/2 IN Knockout, Enclosure: NEMA 4X, Frequency Rating: 50/60 HZ, Amperage Rating: 8.3 AMP, Length: 1.94 IN, Standard: Class I, Division
Specifications
Details
Product Height:
3.50"
Product Width:
3.50"
Product Length:
4.50"
Electrical Category:
Control And Automation
Electrical Subcategory:
Controls And Accessories
Application:
For Mercmaster III - Low Profile, Mercmaster III And Mercmaster III - 400 Series Luminaires, Remote Mounting In FS Boxes
Brand Name:
Appleton
Connection:
(3) 18 AWG Stranded 6 IN Leads
Country Of Origin:
US
Enclosure:
NEMA 4X
Frequency Rating:
50/60
Mounting:
1/2 IN Knockout
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
RoHS Compliance:
Contact Manufacturer
Spec Sheet:
Spec Link
Special Features:
Encapsulated photocontrol provides automatic dusk-to-dawn lighting control in Class I, Division 2 locations; Factory sealed design eliminates the need for an explosionproof enclosure; Can be easily installed in the field; solid-state design for performance
Standard:
Class I, Division 2, Groups A, B, C, D, UL 1604 - Hazardous (classified), C/US UL Listed
Stock Type:
Shelf Stock
Supply Voltage:
120
Type:
PCD2 Series Photocontrol
UNSPSC:
39121524
Warranty Link:
Warranty Information
Weight:
.300 L
